1 Ch. 85 V/10 mA Digital Controlled SiPM Power Supply (with USB) - PCB Mount
A7585D
The A7585D/A7585DU are high voltage regulators specifically designed for SiPM bias. Each has a built in temperature compensation controller with programmable coefficient. The module can be digitally controlled by UART and I2C. A7585DU moreover integrates a USB to UART bridge and it could be powered from USB. Output voltage could be also controlled proportionally to an analog input.
A7585D/A7585DU can provide up to 10 mA and the output voltage could be regulated between 20V and 85V with a resolution of 1 mV. Moreover, the ZEUS control software is provided for free; ZEUS allows to monitor and control multiple modules at same time.
Zeus Software
ZEUS is a Windows compatible software that allows to control multiple A7585DU modules using USB connection. The software is based on a user friendly GUI that allows the parameters configuration and the data logging on file. It integrates real-time plot capabilities (voltage, current and temperature) with the possibility to superimpose measurements from several modules.
ZEUS software is the simplest way to program temperature LUT compensation.
Moreover, a Python Library is available as well.
The Unit is developed in close collaboration with NUCLEAR INSTRUMENTS SRL.
Features
-
Single channel PCB mount High Voltage Power Supply
-
A7585D: SMD version
-
A7585DU: Through-Hole version
-
-
20÷85 V (10 mA) output range
-
Suitable for large SiPM matrix
-
Analog and Digital Control (UART and I2C)
-
Very low ripple (<0.1 mVpp typical)
-
High resolution on voltage and current monitor
-
Programmable temperature compensation
-
Open-source C library for I2C interfacing of multiple devices available on GitHub repository
-
ZEUS Control Software for easy management of the module
-
Python Library available on GitHub repository
-
USB interface (A7585DU Only)
